Hydroxypropyl methylcellulose (HPMC) E5 and E15 are two widely used low‑viscosity grades whose key difference is viscosity, which directly affects solubility, film formation and application performance. Choosing between HPMC E5 and E15 is critical for formulators in pharmaceuticals, coatings, food and adhesives who need consistent processing and final product quality.
HPMC is a non‑ionic, water‑soluble cellulose ether used as a thickener, binder, film former, stabilizer and water‑retention agent in many industries. E‑series grades such as E3, E5, E6 and E15 are defined mainly by viscosity of a 2% aqueous solution, with higher numbers indicating higher viscosity.
- HPMC E5: low viscosity, about 4.0–6.0 mPa·s (or cps) at 2% in water.
- HPMC E15: higher viscosity, about 12.0–18.0 mPa·s (or cps) at 2% in water.
- Both grades share similar chemical structure (methyl and hydroxypropyl substitution) but differ in molecular weight distribution and solution rheology.
These viscosity differences make each grade better suited to specific process requirements, such as immediate‑release vs controlled‑release systems or thin vs thick coatings.
The main difference between HPMC E5 and E15 is their solution viscosity, which affects flow, film thickness, dissolution rate and gel strength.
- HPMC E5: viscosity around 4.0–6.0 mPa·s at 2% in water, giving a relatively thin, free‑flowing solution.
- HPMC E15: viscosity around 12.0–18.0 mPa·s at 2% in water, producing a more viscous and structured solution.
Because of this, HPMC E5 is easier to pump, spray and atomize, while HPMC E15 provides stronger thickening and film‑forming effects.
- E5 tends to form thinner, more flexible films that dissolve faster and are suitable for immediate‑release coatings.
- E15 forms thicker, more robust films with stronger gel structure, supporting controlled or sustained‑release systems and more protective coatings.
In aqueous systems, the higher viscosity of E15 also provides better structural stability, which can help suspend actives or pigments over longer periods.
Both HPMC E5 and E15 are non‑ionic and are generally soluble in cold and hot water, but their dissolution rate and handling behavior differ.
- E5 has a faster dissolution rate in water, especially at room temperature, which can speed up solution preparation and wet granulation.
- E15 dissolves more slowly and hydrates into a stronger gel layer, which supports slower drug release in matrix tablets or thicker coatings.
In terms of organic solvent compatibility, both grades are compatible with many polar organic solvents, but the higher viscosity of E15 may require higher shear or gradual addition to avoid lumping in certain solvent systems. Because both grades are non‑ionic, they typically show good compatibility with electrolytes and many other excipients.
The following table summarizes typical technical parameters that formulators frequently compare when choosing between E5 and E15.
| Parameter | HPMC E5 | HPMC E15 |
|---|---|---|
| Nominal viscosity (2% aq., 20 °C) | ~4.0–6.0 mPa·s (cps) | ~12.0–18.0 mPa·s (cps) |
| Solution flow behavior | Very low viscosity, thin and easy‑flowing | Medium viscosity, more body and structure |
| Dissolution speed in water | Generally faster, shorter hydration time | Slower dissolution, stronger surface gel |
| Film thickness | Thinner films at same solids content | Thicker, more robust films |
| Film flexibility | More flexible and elastic films | Harder, more rigid and durable films |
| Typical use level (pharma coatings) | Lower viscosity at a given concentration, easy spraying | Higher solids needed to reach the same viscosity |
| Main release profile focus | Immediate‑release, rapid dissolution | Controlled‑ or sustained‑release |
Using such a table helps buyers and formulators quickly compare and select suitable grades.
Because of its low viscosity and fast dissolution, HPMC E5 is preferred in applications where fluidity and rapid release are critical.
- Film coatings for immediate‑release tablets and capsules where a thin, uniform coating is required and rapid disintegration is desired.
- Wet granulation binder for tablets, where low solution viscosity helps achieve good granule flow and uniformity.
- Suspending medium in oral liquids with relatively low solids content.
In these systems, E5 allows formulators to maintain manageable viscosity at relatively high solids, which helps keep spray coating and pumping efficient.
- Thin coatings on seeds, food products and confectionery where a light barrier or gloss is needed but not a thick film.
- Adhesives and sealants requiring lower viscosity for good wetting and penetration into porous substrates.
- Food stabilizer and thickener in beverages or sauces where too much viscosity would harm mouthfeel.
These uses benefit from the balance of clarity, film‑forming and low viscosity that HPMC E5 provides.
HPMC E15, with its higher viscosity and stronger gel structure, suits applications requiring better film strength, water retention and controlled release.
- Controlled‑release or sustained‑release tablets, where E15 helps build a thicker gel layer that slows diffusion of the active ingredient.
- Moisture‑barrier or protective coatings combined with other polymers, where a more robust film is needed.
- Capsule coatings that must resist mechanical stress during handling and transport.
In these systems, E15's higher viscosity contributes to more uniform film build and improved mechanical strength.
- Coatings and sealants where a thicker, more protective layer is desired on substrates.
- Viscosity control in systems that must resist sagging or settling, such as high‑solids coatings.
- Food applications requiring increased body, texture and water retention, such as some bakery or dairy systems.
Because E15 builds viscosity quickly, formulators can often reduce total polymer dosage while still achieving the desired rheology.
A structured selection approach improves both performance and cost‑effectiveness for your formulation.
1. Define the target application and release profile
- If you need immediate release or thin coatings, start with E5.
- If you need controlled‑release or thicker barrier coatings, evaluate E15.
2. Set your target viscosity window in the final system
- Determine acceptable viscosity at processing temperature, for example in a tablet coating suspension or liquid product.
- Choose the grade that reaches this window at a practical polymer concentration.
3. Evaluate processing method and equipment limits
- For spray coating, pumping and fine atomization, low viscosity E5 is usually easier to handle.
- If your equipment can handle higher viscosity and you need stronger films, E15 may be more suitable.
4. Consider stability and film performance
- Where flexible films and rapid disintegration are needed, E5 performs well.
- Where durable, rigid or water‑resistant films are key, E15's higher viscosity and gel strength add value.
5. Run pilot trials and adjust concentration
- Start with recommended solids levels from suppliers, then gradually adjust polymer concentration, plasticizer level and any co‑polymers.
- Monitor coating defects, dissolution profiles and mechanical properties to fine‑tune your choice.
This stepwise framework can be turned into a simple internal checklist for R&D and QA teams to standardize grade selection.
Good handling practices help you avoid common problems such as lumping, incomplete dissolution or unstable viscosity.
- Dry blending before hydration: premix HPMC with other dry ingredients such as fillers or sugars to improve dispersion before adding water.
- Gradual addition to water: sprinkle HPMC onto the vortex of cold or room‑temperature water with sufficient agitation to prevent fish‑eyes.
- Hydration time: allow enough time for complete hydration, especially for E15, before evaluating viscosity or starting coating.
- Temperature control: avoid very high temperatures during initial wetting, then increase temperature if needed to adjust viscosity or dissolution behavior.
- pH and additives: although HPMC is non‑ionic, extreme pH and certain salts or surfactants can influence viscosity and stability, so pilot tests are essential.
By following these tips, you can achieve reproducible viscosity and film quality for both E5 and E15‑based systems.
Partnering with an experienced HPMC supplier helps ensure consistent quality, technical support and regulatory compliance, especially for demanding pharmaceutical and food applications.
A strong manufacturer should provide:
- Stable viscosity control across batches, supported by strict quality control on substitution degree, moisture and particle size.
- Application‑driven grades of HPMC, HEMC and HEC tailored to construction, pharma, food and personal care.
- Technical support for formulation optimization, troubleshooting and process scale‑up.
- Documentation and regulatory support, including COA, MSDS and pharmacopeia‑compliant specifications for relevant markets.
By highlighting your research, development and production capabilities as a professional cellulose ether manufacturer, you can build trust and long‑term cooperation with end users.
If you are developing a new coating, tablet, food or adhesive product and are unsure whether HPMC E5 or E15 is the best fit, you are welcome to contact our technical team with your process parameters and performance targets. We will evaluate your formulation needs, recommend suitable cellulose ether grades from our HPMC, HEMC and HEC portfolio, and provide trial samples and technical guidance to help you achieve stable, cost‑effective and high‑performance products.
Contact us to get more information!
No. E15 gives thicker, more robust films, but E5 is often better for thin, immediate‑release coatings that require low viscosity and fast dissolution. The right choice depends on your target release profile and process limits.
A direct one‑to‑one replacement usually changes viscosity, film thickness and dissolution behavior, so you should not switch grades without optimization. You will need to adjust polymer concentration, plasticizer level and sometimes processing parameters such as spray rate and inlet temperature.
Yes, both grades are non‑ionic and generally compatible with many polymers such as PVP, PEG and some acrylics, as well as common excipients and fillers. However, you should always run stability and dissolution tests to confirm there are no negative interactions in your specific formulation.
HPMC powders are relatively stable but can absorb moisture, which may affect flowability and apparent viscosity if stored improperly. Store both E5 and E15 in sealed packaging, in a cool, dry environment away from direct sunlight to maintain performance over shelf life.
Yes, certain HPMC E grades are used as food thickeners, stabilizers and film formers, especially in bakery, dairy and vegetarian capsule applications. Always check the specific regulatory status and purity of the grade you intend to use to ensure it meets food‑grade standards in your target market.
